Gewicht 26,8 kg
Steuersatz ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface
Dämpfer Hardware Top: 54mm Trunnion Mount, Bottom: 22.2x8mm
Max. Systemgewicht 150 kg
Max. Fahrergewicht 120 kg
ABS-Technologie Bosch ABS Pro
Rahmen Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
Größe Size Split: 27.5: S // 29: M, L, XL
Federgabel Fox 36 Float AWL RAIL 2.0, Tapered, 15x110mm, E-Bike Optimized, 140mm
Motor Bosch Drive Unit Performance Line CX max. 100Nm (BDU38)
Remote Bosch Purion 200 with Integrated Display
Akku Bosch PowerTube 800
Ladegerät Bosch 2A
Dämpfer Fox Float Rhythm RC, 205x60mm (27.5: 185x55mm), Adjustable LSR w/ 2-Pos. Lever, Trunnion Mount
Bremsanlage Shimano XT BR-M8220, Hydr. Disc Brake w/ Front ABS (203/203)
Schaltwerk Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Schalthebel Shimano XT SL-M8100-IR, Direct Attach
Kurbelgarnitur ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
Kassette Shimano Deore CS-M6100, 10-51T
Kette KMC e12
Kettenführung Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Vorbau CUBE Performance Stem E-MTB 35, FPI-Link
Lenker CUBE Rise Trail Bar 35
Griffe ACID Hybrid Perform
Laufradsatz ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
Reifen Schwalbe Nobby Nic, Performance, 2.6
Sattel ACID Venec EMTB Plus 145
Sattelstütze CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Pedale ACID PP MTB
Farbe blueiris´n´black
