Gewicht 24,2 kg
Steuersatz ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Dämpfer Hardware Front: 30x8mm, Rear: DU-Bushing 12.7mm
Max. Systemgewicht 160 kg
Max. Fahrergewicht 125 kg
Rahmen C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Größe Size Split: 27.5: S // 29: M, L, XL
Federgabel Fox 36 Float AWL HD Sport RAIL 2.0 R, Tapered, 15x110mm, E-Bike Optimized, 150mm
Motor Bosch Drive Unit Performance Line CX max. 100Nm (BDU38)
Remote Bosch System Control, incl. Mini Remote
Akku Bosch PowerTube 800
Display Bosch Purion 400
Ladegerät Bosch 2A
Dämpfer Fox Float Rhythm R, 230x60mm (27.5: 210x55mm), Adjustable LSR
Bremsanlage Shimano BR-MT420, Hydr. Disc Brake (203/203)
Schaltwerk Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Schalthebel Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
Kurbelgarnitur ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
Kassette Shimano Deore CS-M6100, 10-51T
Kette KMC e12
Kettenführung Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Vorbau CUBE Performance Stem E-MTB 35, FPI-Link
Lenker CUBE Rise Trail Bar 35
Griffe ACID Disrupt
Laufradsatz ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
Reifen Schwalbe Nobby Nic, Performance, 2.6
Sattel ACID Venec EMTB Trail 140
Sattelstütze CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Sattelklemme CUBE Semi-Integrated
Pedale ACID PP MTB
Farbe smaragdgrey´n´prism
