Gewicht 24,9 kg
Steuersatz ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Laufradsatz Newmen Performance 30 base/strong, 28/32 Spokes, 15x110mm / 12x148mm, Tubeless Ready
Dämpfer Hardware Front: 30x8mm, Rear: DU-Bushing 12.7mm
Max. Systemgewicht 160 kg
Max. Fahrergewicht 125 kg
ABS-Technologie Bosch ABS Pro
Rahmen C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Größe Size Split: 27.5: S // 29: M, L, XL
Federgabel Fox 36 Float Rhythm GRIP, Tapered, 15x110mm, E-Bike Optimized, 150mm
Motor Bosch Drive Unit Performance Line CX max. 100Nm (BDU38)
Remote Bosch Mini Remote
Akku Bosch PowerTube 800
Display Bosch Kiox 400C
Ladegerät Bosch 4A
Dämpfer Fox Float Performance, 230x60mm (27.5: 210x55mm), Adjustable LSR w/ 2-Pos. Lever
Bremsanlage Shimano XT BR-M8220, Hydr. Disc Brake w/ Front ABS (203/203)
Schaltwerk Shimano XT Di2 RD-M8260-SGS, 12-Speed, Electronic Shifting System
Schalthebel Shimano XT Di2 SW-M8250-IR, Direct Attach
Kurbelgarnitur ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
Kassette Shimano Deore CS-M6100, 10-51T
Kette Shimano CN-M6100
Kettenführung Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Vorbau CUBE Performance Stem E-MTB 35, FPI-Link
Lenker CUBE Rise Trail Bar 35
Griffe ACID Disrupt
Vorderreifen Conti Kryptotal Front, Enduro Soft, Tubeless Ready, 2.4
Hinterreifen Conti Kryptotal Rear, Downhill Soft, Tubeless Ready, 2.4
Sattel ACID Venec EMTB Trail 140
Sattelstütze CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Sattelklemme CUBE Semi-Integrated
Pedale ACID PP MTB
Farbe stellar´n´grey
