Gewicht 18,1 kg
Steuersatz ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment
Dämpfer Hardware Front: 30x8mm, Rear: DU-Bushing 12.7mm
Max. Systemgewicht 135 kg
Max. Fahrergewicht 110 kg
Rahmen C:62® Monocoque Advanced Twin Mold Technology, Efficient Trail Control, FSP 4-Link. Agile Trail Geometry, Boost 148, UDH™, Fully Integrated Battery, Advanced Internal Cable Routing
Größe S, M, L, XL
Federgabel Fox 34 Float Rhythm GRIP, Tapered, 15x110mm, 140mm
Motor Bosch Drive Unit Performance SX max. 60Nm (BDU31)
Remote Bosch System Control, incl. Mini Remote
Akku Bosch CompactTube 400
Ladegerät Bosch 2A
Dämpfer Fox Float Rhythm RC, 210x55mm, Adjustable LSR w/ 2-Pos. Lever
Bremsanlage Shimano XT BR-M8120, Hydr. Disc Brake (203/180)
Schaltwerk Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Schalthebel Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
Kurbelgarnitur ACID MTB Hybrid Carbon, 32T
Kassette Shimano Deore CS-M6100, 10-51T
Kette KMC e12
Kettenführung Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Vorbau CUBE Stereo Stem w/ Cable Routing
Lenker Newmen Evolution SL 318.25, 780mm
Griffe ACID Disrupt, Soft Compound
Laufradsatz Newmen Performance 30 base/base, 28/28 Spokes, 15x110mm / 12x148mm, Tubeless Ready
Reifen Schwalbe Nobby Nic, Addix Performance, Kevlar, 2.4
Sattel ACID Venec EMTB Trail 140
Sattelstütze CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Pedale ACID PP MTB
Farbe blackline
